Figure 28 continued: Code Update SIL
Page 8 of 9
17
Return/Exhaust Fan
Capacity Control
Method
0=None

2=Building Pressure
3=Speed
4=OADamper
●
●
●
●
18
Second Duct
Pressure Sensor

1= Yes
●
●
19
Entering Fan Temp
Sensor

1=Yes
●
●
●
●
20
Energy Recovery

1=ConstSpdWhl/NoRH
2=VarSpdWhl/Danfoss
3=VarSpdWhl/MD2
4=VarSpdWhl/MD3
5=VarSpdWhl/ABB
6=ConstSpdWhl/wRH
●
●
●
●
21
Cooling Circuit
Type

1=2,3 or 4 Circ. Water
Condenser
2=2 Circ. Air Condenser
Values 0 and 1
are valid only
when Position 1 =
1 (SCU)
●
●
●
22
Head Pressure
Control

1=Yes
This position is
valid only when
Position 1 = 1
(SCU).
●
23
Bypass Valve
Control

1=Bypass
This position is
valid only when
Position 1 = 1
(SCU).
●
24, 25, 26
Unit Size
Three digits
●
●
●
●
●
27
Refrigerant Type

1=R407C
2=R410A
●
●
●
●
●
28
Reheat Type

1=StgHG
2=ModHG
3=StdHtRht
4=ModLSC
5=ModHG&LSC
●
●
●
●
29
Unit Voltage
0=208/60Hz
1=230/60Hz

3=575/60Hz
4=208/50Hz
5=230/50Hz
6=460/50Hz
7=575/50Hz
●
●
●
●
●
30
EVType
0=None
1=EVB_Sag
2=EVB_DF
3=MTIII_Sag
4=MTIII_DF
5=MTIII_Sag_DF
6=MTIII_DF_Sag
7=MTIII_DF_C
●
●
