Figure 18, Navigation, Part C
View/Set Unit
Status/Settings

AWM Setup (view/set unit)
Set-Up

Apply Changes
R/W
Temperatures

DHCP
R/W
Condenser

Actual IP Address
R
Date/Time/Schedules

Actual Mask
R
Power Conservation

Actual Gateway
R
LON Setup

Given IP Address
R/W
BACnet IP Setup

Given Mask
R/W
BACnet MSTP Setup

Given Gateway
R/W
Modbus Setup

AWM BSP
R
AWM Setup

Design Conditions (view/set
unit)
Design Conditions

Evap Entering Water Temp @
Design
R
Alarm Limits

Evap Leaving Water Temp @
Design
R
Alarm Limits (view/set unit)
Menu Password

Low Pressure Hold Setpoint
R
Low Pressure Unload Setpoint
R
View/Set Circuit

Menu Password (view/set
unit)
Status/Settings

Password Disable
R/W
Compressor

Status/Settings (view/set
circuit)
Status Circuit 1
Time Until Restart

Circuit Status
R
Compressor 1 Cycle Time
Remaining
R
Circuit Mode
R/W
Compressor 2 Cycle Time
Remaining
R
Circuit Capacity
R
Compressor 3 Cycle Time
Remaining
R
Compressor 4 Cycle Time
Remaining
R
Status Circuit 2

Status Circuit 3

Alarms

Status Cricuit 4

Alarm Active

Alarm Log

Compressor (view/set circuit)
Compressor 1 Circuit 1
Scheduled Maintenance
Next Maintenance Month/Year
R/W
Run Hours
R
Service Support Reference
R
Number Of Starts
R
Alarm Active (Alarms)
About This Chiller
Active Alarm 1
R
Model Number
R
R
G. O. Number
R
Active Alar
R
Unit Serial Number
R
Acknowledge All
R/W
Starter Model Number(s)
R
Starter Serial Number(s)
R
Alarm Log (Alarms)
Firmware Version
R
Alarm Entry 1
R
Application Version
R
…
R
Application GUID
R
Alarm Entry 50
R
HMI GUID
R
OBH GUID
R
Note: Parameters with an “*” are available without entering a password.
