Figure 2, Operation Commands
4.3 Controller Description
4.3.1 Hardware Structure
The MicroTech control system for water cooled screw chillers consists of a main unit controller with a number of extension
I/O modules attached depending on the chiller size and configuration.
Up to two optional BAS communication modules may be included on request.
An optional Remote Operator Interface panel may be included, connected with up to nine units.
