Daikin RELQ72TAYDA - Safety Devices Setting; FXFQ-T

74
RELQ-TATJA / TAYDA / TAYCA EDUS371705C-D
25. Safety Devices Setting
25.1 FXFQ-T
Model FXFQ07TVJU FXFQ09TVJU FXFQ12TVJU FXFQ15TVJU FXFQ18TVJU
Printed circuit board fuse 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A
Drain pump thermal fuse °F(°C) – – – – –
Fan motor thermal protector °F(°C) – – – – –
Fan motor thermal fuse °F(°C) – – – – –
Model FXFQ24TVJU FXFQ30TVJU FXFQ36TVJU FXFQ48TVJU
Printed circuit board fuse 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A
Drain pump thermal fuse °F(°C) – – – –
Fan motor thermal protector °F(°C) – – – –
Fan motor thermal fuse °F(°C) – – – –
C: 3D086932C
25.2 FXZQ-TA
Model FXZQ05TAVJU FXZQ07TAVJU FXZQ09TAVJU FXZQ12TAVJU FXZQ15TAVJU FXZQ18TAVJU
Printed circuit board fuse 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A
Fan motor thermal fuse °F(°C) – – – – – –
Fan motor thermal protector °F(°C) – – – – – –
Drain pump fuse °F(°C) – – – – – –
C: 4D110603
25.3 FXUQ-P
Model FXUQ18PVJU FXUQ24PVJU FXUQ30PVJU FXUQ36PVJU
Printed circuit board fuse 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A
Drain pump thermal fuse °F(°C) – – – –
Fan motor thermal protector °F(°C) – – – –
Fan motor thermal fuse °F(°C) – – – –
C: 3D090213
25.4 FXEQ-P
Model FXEQ07PVJU FXEQ09PVJU FXEQ12PVJU FXEQ15PVJU FXEQ18PVJU FXEQ24PVJU
Printed circuit board fuse A1P 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A
Fan motor thermal protector °F(°C)
OFF: 223±9
(106±5)
ON: 205±27
(96±15)
OFF: 223±9
(106±5)
ON: 205±27
(96±15)
OFF: 223±9
(106±5)
ON: 205±27
(96±15)
OFF: 223±9
(106±5)
ON: 205±27
(96±15)
OFF: 223±9
(106±5)
ON: 205±27
(96±15)
OFF: 223±9
(106±5)
ON: 205±27
(96±15)
C: 4D098709
