Removal of Outer Panels / Fan Motor Si00-772
4 Removal Procedure
6
Unfasten the hooks.
Pull and remove the
front panel.

The front panel has 4 hooks.
3. Remove the fan motor.

Nut size: M6
1
Unscrew the washer-
fitted nut of the outdoor
fan.
2
Remove the outdoor
fan.

When reassembling, align
the mark of the outdoor
fan with the D-cut section of
the motor shaft.
Step
Procedure Points
Hooks
(R3243)
Outdoor fan
(R12416)
(R19146)
10 mm
(0.39 inch)
D-cut
(R3245)
