Daikin RXS20K3V1B Installation Manual

■English 8
6. Relling the refrigerant
Checkthetypeofrefrigeranttobeusedonthemachinenameplate.
Precautions when adding R410A
Fill from the gas pipe in liquid form.
Itisamixedrefrigerant,soaddingitingasformmaycausetherefrigerantcompositiontochange,preventingnormaloperation.
1) Beforelling,checkwhetherthecylinderhasasiphonattachedornot.(Itshouldhavesomethinglike“liquidllingsiphonattached”displayedonit.)
Filling a cylinder with an attached siphon
Stand the cylinder upright when filling.
There is a siphon pipe inside, so the
cylinder need not be upside-down to fill with
liquid.
Filling other cylinders
Turn the cylinder upside-down
when filling.
•BesuretousetheR410Atoolstoensurepressureandtopreventforeignobjectsentering.
3
5
6
2
1
4
Please fill in with indelible ink,
■
1
the factory refrigerant charge of the product,
■
2
the additional refrigerant amount charged in the field and
■
1 + 2
the total refrigerant charge
on the refrigerant charge label supplied with the product.
Important information regarding the refrigerant used
This product contains fluorinated greenhouse gases covered by
the Kyoto Protocol. Do not vent gases into the atmosphere.
Refrigerant type:
R410A
GWP
(1)
value: 1975
(1)
GWP = global warming potential
1 factory refrigerant charge of the
product:
see unit name plate
2 additional refrigerant amount
charged in the field
3 total refrigerant charge
4 Contains fluorinated greenhouse
gases covered by the Kyoto
Protocol
5 outdoor unit
6 refrigerant cylinder and manifold
for charging
The filled out label must be adhered in the
proximity of the product charging port (e.g.
onto the inside of the stop valve cover).
NOTE
NationalimplementationofEUregulationoncertainuorinatedgreenhousegasesmayrequiretoprovidetheappropriateofcial
nationallanguageontheunit.Thereforeanadditionalmultilingualuorinatedgreenhousegaseslabelissuppliedwiththeunit.
Stickinginstructionsareillustratedonthebacksideofthatlabel.
Standby Electricity Saving
The standby electricity saving function turns off power supply to the outdoor unit and sets the indoor unit
into standby electricity saving mode, thus reducing the power consumption of the air conditioner.
The standby electricity saving function works on the following indoor units.
For all models after the FTXS20/25/35J type
CAUTION
•The standby electricity saving function cannot be used for models other than the specied ones.
■
Procedure for turning on standby electricity saving
function
1)Checkthatthemainpowersupplyisturnedoff.Tur nitoffif
hasnotbeenturnedoff.
2)Removethestopvalvecover.
3)Disconnecttheselectiveconnectorforstandbyelectricity
saving.
4)Turnonthemainpowersupply.
1
2
3
1
2
3
Standby electricity saving
function off.
Standby electricity saving
function on.
The standby electricity saving function is turned off before shipping.
CAUTION
•Beforeconnectingordisconnectingtheselectiveconnectorforstandbyelectricitysaving,makesurethatthemainpower
supplyisturnedoff.
•
Theselectiveconnectorforstandbyelectricitysavingisrequiredifanindoorunitotherthantheaboveapplicableonesisconnected.
01_EN_3P297037-2D.indd 8 11/1/2012 11:04:43 AM
