Daikin RXS20K3V1B Installation Manual

■English 10
Wiring
WARNING
•Donotusetappedwires,strandedwires,extensioncords,orstarburstconnections,astheymaycauseoverheating,
electricalshock,orre.
•Donotuselocallypurchasedelectricalpartsinsidetheproduct.(Donotbranchthepowerforthedrainpump,etc.,fromthe
terminalblock.)Doingsomaycauseelectricshockorre.
•Besuretoinstallanearthleakdetector.(Onethatcanhandlehigherharmonics.)
(Thisunitusesaninverter,whichmeansthatitmustbeusedanearthleakdetectorcapablehandlingharmonicsinorderto
preventmalfunctioningoftheearthleakdetectoritself.)
•Useanall-poledisconnectiontypebreakerwithatleast3mmbetweenthecontactpointgaps.
•Donotconnectthepowerwiretotheindoorunit.Doingsomaycauseelectricshockorre.
•Donotturnonthesafetybreakeruntilallworkiscompleted.
1)Striptheinsulationfromthewire(20mm).
2)Connecttheconnectionwiresbetweenthe
indoorandoutdoorunitssothattheterminal
numbersmatch.Tightentheterminalscrews
securely.Werecommendaatheadscrewdriver
beusedtotightenthescrews.Thescrewsare
packedwiththeterminalboard.
1
2
3
123
LN
Safety
breaker
16A
Earth leakage
circuit breaker
Earth
Inter-unit wire
4-core 1.5mm² or more
H05RN
Firmly fix the wires with
the terminal screws.
Outdoor unit
Indoor
unit
Power supply
50Hz 220-240V
Firmly fix the wires with
the terminal screws.
Power supply wire
3-core 2.5mm² or more
H05RN
1
2
3
Use the specified wire type
and connect it securely.
Firmly secure wire retainer so wire
terminations will not receive external stress.
1
2
3
L
N
Power supply
terminal block
Shape wires so
that the service lid
and stop valve
cover fit securely.
Observethenotesmentionedfollowingwhenwiringtothepowersupplyterminalboard.
Precautionstobetakenforpowersupplywiring.
CAUTION
•Whenconnectingtheconnectionwirestotheterminalboardusingasinglecorewire,besuretoperformcurling.
Problemswiththeworkmaycauseheatandres.
Strip wire end
to this point.
Excessive strip length
may cause electrical
shock or leakage.
Good Wrong
Good Wrong
Stripping wire at terminal block
•Ifthestrandedwiresmustbeused,makesuretousetheround
crimp-styleterminalforconnectiontothepowersupplyterminalblock.
Placetheroundcrimp-styleterminalsonthewiresuptothecovered
partandsecureinplace.
Stranded wire
Round crimp-style
terminal
3)Pullthewireandmakesurethatitdoesnotdisconnect.Thenxthewireinplacewithawirestop.
01_EN_3P297037-2D.indd 10 11/1/2012 11:04:44 AM
