SiBE06-708_A Printed Circuit Board Connector Wiring Diagram
Printed Circuit Board Connector Wiring Diagram 20
1. Printed Circuit Board Connector Wiring Diagram
1.1 Indoor Unit
Connectors and
Other Parts
PCB(1): Sensor PCB
PCB(2): Control PCB
PCB(3): Service PCB
PCB(4): Display PCB
1) S49 Connector for control PCB
2) RTH2 (R1T) Room temperature thermistor
1) S1 Connector for fan motor
2) S21 Connector for centralized control (HA)
3) S26 Connector for service PCB
4) S32 Connector for indoor heat exchanger thermistor
5) S41 Connector for lower air outlet motor
6) S42 Connector for swing motor
7) S46 Connector for display PCB
8) S48 Connector for sensor PCB
9) H1, H2, H3 Connector for terminal board
10) E1 Connector for earth
11) V1, V2 Varistor
12) JA Address setting jumper
∗
Refer to page 258 for detail.
JB Fan speed setting when compressor stops for thermostat OFF
JC Power failure recovery function
∗
Refer to page 261 for detail.
13) FU1 (F1U) Fuse (3.15A, 250V)
14) LED A LED for service monitor (green)
1) S27 Connector for control PCB
2) SW2-4 Switch for upward airflow limit setting
∗
Refer to page 261 for detail.
3) SW4 (S4W) Switch for air outlet selection
∗
Refer to page 60, 66 for detail.
1) S47 Connector for control PCB
2) SW1 (S1W) Forced operation ON/OFF button
3) LED1 (H1P) LED for operation (green)
4) LED2 (H2P) LED for timer (yellow)
