Daikin Super Multi NX FDKS60CVMB

SiBE121021_C Outdoor Unit - 80/90 Class
Removal Procedure 409
6
Remove the 2 screws
on the partition plate
(1).
7
Remove the screw at
the bottom left of the
front panel (1).
8
Remove the screw at
the bottom of the left
side.
Step
Procedure Points
(R10382)
Partition plate (1)
(R10383)
(R6393)
