PhysICal daTa
www.DaikinApplied.com 27 IM 1137-4 • TEMPLIFIER
®
MODEL TGZ
Table 16: TGZ 110B – 120B
TGZ Unit Model TGZ110B TGZ120B
No. Of Circuits 2 2
COMPRESSORS (2)
Nominal Horsepower 25 30 30 30
Number per Circuit 2 2 2 2
Staging, 4 Stages, Circuit #1 in Lead 23/50/73/100 25 / 50 / 75 100
Staging, 4 Stages, Circuit #2 in Lead 27/50/77/100 25 / 50 / 75 100
Oil Charge, per compr. Oz (l) 200 (5.9) 213 (6.3) 213 (6.3)
CONDENSER
Number 1 1
No. Refrigerant Circuits 2 2
Diameter, in. (mm) 16.0 (406.4) 16.0 (406.4)
Tube Length, in (mm) 120 (3048) 120 (3048)
Design W.P.,psig (kPa):
Refrigerant Side 500 (3447) 500 (3447)
Water Side 232 (1599) 232 (1599)
Relief Valve Setting, psig (kPa) 500 (3447) 500 (3447)
No. Of Water Passes - Standard 4 4
No. Of Water Passes - Optional 2 2
Water Volume, gallons (l) 35.4 (134) 35.4 (134)
Pump-Down Refrig Capacity lb. (kg) (3) 252 (114) 252 (114)
Connections:
Water In & Out, in., (mm) (4 Pass) 4 (102) 4 (102)
Water In & Out, in., (mm) (2 Pass) 5 (127) 5 (127)
Relief Valve, Flare in., (mm) 5/8 (15.9) 5/8 (15.9)
Purge Valve, Flare in., (mm) 5/8 (15.9) 5/8 (15.9)
Vent & Drain, in (mm) FPT 1/2 (12.7) 1/2 (12.7)
Liquid Subcooling Integral Integral
EVAPORATOR
Number 1 1
No. Refrigerant Circuits 2 2
Water Volume, gallons (1) 9.7 (36.7) 9.7 (36.7)
Refrigerant Side D.W.P., psig, (kPa) 450 (3102) 450 (3102)
Relief Valve Setting, psig (kPa) 450 (3102) 450 (3102)
Water Side D.W.P., psig, (kPa) 450 (3102) 450 (3102)
Water Connections:
In & Out, in. (mm) victaulic 3 (76) 3 (76)
Drain & Vent Field Supplied Field Supplied
UNIT DIMENSIONS
Length, in. (mm) 149 (3784) 149 (3784)
Width, in. (mm) 34.5 (876) 34.5 (876)
Height, in. (mm) 67 (1702) 67 (1702)
UNIT WEIGHTS
Operating WT., lb., (kg) 5373 (2437) 5319 (2412)
Shipping WT., lb. (kg) 4967 (2253) 4913 (2228)
R-134a Ref. Charge, lb. (kg) 110 (49.9) 110 (49.9) 110 (49.9) 110 (49.9)
