dImensIonal drawIngs
www.DaikinApplied.com 19 IM 1137-4 • TEMPLIFIER
®
MODEL TGZ
dImensIonal drawIngs
Figure 17: Dimensions, TGZ040B – TGZ060B, Standard 4-pass Condenser
NOTE: See “Weights” on Table 12 on page 24 for lifting and corner weights. Left-hand condenser connections are an
available option.
