Table 27: TGZ Temperature Limits
Table 28: TGZ Flow Limits
NOTE: ELWT=Evaporator Leaving Water Temperature, CLWT=Condenser Water Leaving Temperature.
Compressor POE Oil
The oil level should be watched carefully upon initial start-up
and for sometime thereafter. Compressor oil must be one of
the following: Copeland brand Ultra 22 CC, Copeland brand
Ultra 32 CC, Copeland brand Ultra 32-3MAF, Mobil EAL Artic
22 CC, or Uniqema RL32-3MAF.
This is synthetic polyolester oil with anti-wear additives and is
highly hygroscopic. Care must be taken to minimize exposure
of the oil to air when charging oil into the system. Oil can
be added to the compressor through the oil ll hole on the
compressor. To add oil, pump in the necessary oil.
Sightglass and Moisture Indicator
A clear glass of liquid indicates that there may be an adequate
refrigerant charge in the system to provide proper feed through
the expansion valve. Bubbling refrigerant in the sightglass
indicates that the system is short of refrigerant charge.
Refrigerant gas ashing in the sightglass could also indicate
an excessive pressure drop in the line, possibly due to a
clogged lter-drier or a restriction elsewhere in the system. An
element inside the sightglass indicates what moisture condition
corresponds to a given element color. If the sightglass does
not indicate a dry condition after about 12 hours of operation,
the oil should be tested for acid and the lter-driers changed if
necessary.
Unit Nominal Tons 40 50 60 80 100 110 120 150 170 190
Evaporator GPM Range
10 F Water Temp Delta-T, 65ELWT/130CLWT 72 100 121 162 189 218 246 283 326 369
16-6 Water Temp Delta-T, 65ELWT/130LWT 45 - 120 62 - 167 75 - 202 101 - 270 118 - 315 136 - 363 154 - 410 177 - 472 204 - 543 231 - 615
10 Water Temp Delta-T, Full Unit Range 34 - 120 45 - 167 55 - 202 83 - 270 98 - 315 113 - 363 128 - 410 147 - 472 169 - 543 192 - 615
Condenser GPM Range - 4 Pass Cond
20 F Water Temp Delta-T, 65ELWT/130CLWT 47 64 77 103 120 138 156 180 207 234
40-15 F Water Temp Delta-T, 65ELWT/130CLWT 23 - 63 32 - 86 38 - 103 51 - 138 60 - 160 69 - 184 78 - 208 90 - 240 103 - 276 117 - 312
Condenser GPM Range - 2 Pass Cond
10 F Water Temp Delta-T, 65ELWT/130CLWT 94 128 154 206 240 276 312 360 414 468
15 F Water Temp Delta-T, 65ELWT/130CLWT 63 85 103 137 160 184 208 240 276 312
Cooling Cycle
Min.
Temp
Max
Temp Note:
Evaporator Leaving Water Temp.
40° F
60° F In Cooling Cycle controlling Evap LWT - The Maximum Setpoint temp is 60°F
Condenser Leaving Water Temp 70° F 160° F With Evap LWT above 50°F, the Cond LWT must be 30°F above Evap. LWT
Evaporator Water Delta-T 6° F 16° F
With Glycol in Evap - Evap LWT 15° F 60° F With Evap LWT below 40°F, the Cond EWT must not exceed 120°F above the Evap LWT.
Heating Cycle
Evaporator Leaving Water Temp 40° F 85° F With Evap LWT above 70°F, the Cond LWT must be 30°F above Evap LWT
Condenser Leaving Water Temp 110° F 160° F
Evaporator Water Delta-T 6° F 16° F
Condenser Water Delta - T
with 2 Pass Condenser Water Flow 10° F 15° F Cond Water Temp Delta-T should be 10°F minimum for good condenser liquid subcooling
with 4 Pass Condenser Water Flow 15° F 40° F
