Daikin Trailblazer AGZ110-130E User Manual

IOM 1206-13 • TRAILBLAZER
®
MODEL AGZ CHILLERS 38 www.DaikinApplied.com


Table 4: Refrigerant Charge - Microchannel Units
Unit
Models
Microchannel Coil Unit Operating Charge - lbs (kg)
Packaged Units 
  
Circuit 1 Circuit 2 Circuit 1 Circuit 2 Circuit 1 Circuit 2
030E 17 (7.7) 17 (7.7) 15 (16.8) 15 (16.8)
035E 16 (7.3) 16 (7.3) 14 (6.4) 14 (6.4)
040E 23 (10.5) 23 (10.5) 21 (9.5) 21 (9.5)
045E 23 (10.5) 23 (10.5) 21 (9.5) 21 (9.5)
050E 23 (10.5) 23 (10.5) 21 (9.5) 21 (9.5)
055E 23 (10.5) 23 (10.5) 21 (9.5) 21 (9.5)
060E 23 (10.5) 23 (10.5) 21 (9.5) 21 (9.5)
065E 23 (10.5) 23 (10.5) 21 (9.5) 21 (9.5)
070E 23 (10.5) 23 (10.5) 21 (9.5) 21 (9.5)
075E 46 (20.9) 46 (20.9) 49 (22) 49 (22)
076E 43 (19.6) 43 (19.6) 46 (20.9) 46 (20.9)
080E 46 (20.9) 46 (20.9) 49 (22) 49 (22)
081E 43 (19.6) 43 (19.6) 46 (20.9) 46 (20.9)
 48 (21.8) 48 (21.8) 51 (23) 51 (23)
 45 (20.5) 45 (20.5) 48 (21.8) 48 (21.8)
100E 48 (21.8) 50 (22.7) 52 (24) 52 (24)
101E 45 (20.5) 47 (21.4) 48 (21.8) 50 (22.7)
110E 64 (29.1) 64 (29.1) 69 (31) 69 (31)
120E 65 (29.5) 65 (29.5) 69 (31) 69 (31)
130E 65 (29.5) 65 (29.5) 69 (31) 69 (31)
140E 76 (34.5) 76 (34.5) 82 (37) 82 (37)
150E 76 (34.5) 76 (34.5) 82 (37) 82 (37)
161E 78 (35.4) 78 (35.4) 84 (38) 84 (38)
170E 80 (36.3) 80 (36.3) 86 (39) 86 (39)
180E 80 (36.3) 80 (36.3) 86 (39) 86 (39)

87 (39.5) 87 (39.5) 95 (43) 95 (43)
211E
91 (41.3) 91 (41.3) 99 (45) 99 (45
226E 107 (48.6) 107 (48.6) 119 (55) 119 (55)
241E 111 (50.4) 111 (50.4) 121(55) 121(55)
