Si50-203 Required Tools
Semi-Hermetic Single Screw Compressor Version III 33
Jig (1) [Lock Nut Tightening Jig]
Applicable
model
ZH3_
ZH5F, ZH7F
ZH9F
ZH5G
ZH7G, ZH9G
150
200
250
150
200
7.0
7.6
8.1
7.0
8.1
5
6
7
6
7
76.3
89.1
101.6
76.3
101.6
66
75
92
70
86
10
10
12
10
11
Material
STPG370E
65A, sch80
STPG370E
80A, sch80
STPG370E
90A, sch80
STPG370E
65A, sch80
STPG370E
90A, sch80
(Z0115)
(through hole)
(4 locations)
