Dali Kubik - Connections; Understanding Connections

8
KUBIK XTRA connector
Connect the cable supplied with the KUBIK FREE XTRA.
Adjust the L-L+R-R button on the back of the KUBIK FREE (see page 9) to reflect the position of the
KUBIK FREE.
USB connector
Connect a Micro USB cable to the KUBIK FREE.
Note – The Micro USB input only works with a PC or MAC (iPad when using the Apple Camera
Connection Kit).
Optical connector
Connect an optical cable (TOSLINK) to the KUBIK FREE.
AUX connector
Connect an analogue source via a RCA (Cinch) cable.
Subwoofer connector
Connect any active Subwoofer to the KUBIK FREE.
The KUBIK FREE automatically activates the Subwoofer output when the cable is connected.
Power cord connector
KUBIK FREE connector
Adjust the L-L+R-R button on the back of the KUBIK FREE (see page 9) to reflect the position of the
KUBIK FREE.
1
2
3
4
5
6
7
CONNECTIONS
CONNECTIONS
