DALI SUB E-9 F
Frequency Range [+/- 3] dB [Hz] 35 - 190
Input Impedance [kohm] 25
Maximum SPL [dB] 109
Crossover Frequencies [Hz] 40 - 120
Low Frequency Driver(s) 1 x 9” long stroke
Enclosure Type Bass reflex
Bass Reflex Tuning Frequency [Hz] 36.0
Connection Input(s) RCA, Stereo (low-pass filtered) LFE (Mono)
Recommended Placement Floor, near wall or corner
Magnetic Shielding No
Max. Amplifier Power Output [RMS Watts] 220
Continous IEC Power Output [RMS Watts] 170
Max. Power Consumption [Watts] 250
Dimensions (H x W x D) [mm] 307 x 287 x 310
Dimensions (H x W x D) [inches] 12.1 x 11.3 x 12.2
Weight [kg/lb] 11.8/26.0
TABLE 2 - DALI SUB E-9 F TECHNICAL SPECIFICATIONS
39
All technical specifications are subject to change without notice.
