Dalla Corte Evolution - Page 28

28
P1 Dose button - One short coffee
P2 Dose button - Two short coffees
P3 Free dose and/or Stop button
P4 Dose button - One long coffee
P5 Dose button - Two long coffees
P6 Group head On/Off button
P7 Cup warmer On/Off button
led1 Button P1
led2 Button P2
led3 Button P3
led4 Button P4
led5 Button P5
led6 Button P6
led7 Auto-fill
led8 Boiler
led9 Cup warmer
led10 Line (indicates power on)
Pic. 3
led1
led4
led3
led6
P1
P4
P5
led2
led5
P3
P6
led8 led10
led7
P7
led9
