30 |
L1
L12
L3
L8
L5
L10
L2
L7
L4
L9
L6
M
L13-L17
L11
Pic.2
Pic.3
25
4
3
7
1
8
9
K
J
6
LEGEND
1
ON/OFF switch
2
Multi-function dial knob
3
Tray
4
Steam wand
5
Steam knob
6
Hot water outlet
7
Steam boiler pressure gauge
8
Pump pressure gauge
9
Portafilter
J
Manual pouring lever yoke
K
Group head pressure gauge
LEGEND
L1 Single shot
L2 Double shot
L3 Hot water pouring - 1 dose
L4 Hot water pouring - 2 doses or MCS
L5 Lever yoke manual pouring
L6 Steam boiler cleaning
L7 Power ON
L8 Group temperature OK
L9 Boiler temperature OK
L10 Auto-fill ON
L11 BT
L12 Alarms
L13-L17 Lever yoke position
M Multi-function dial knob
