Dalla Corte ZERO BARISTA - Controls on Machine Front

5-2
ESPRESSO “ZERO BARISTA” COFFEE MACHINES - OPERATING INSTRUCTIONS
GENERAL
SAFETY
GENERAL
DESCRIPTION
USE
MAINTENANCE
TRANSPORT AND
INSTALLATION
5.1 CONTROLS ON MACHINE FRONT
1 Steam lever 4 Button strip for dispensing unit coffee 2
2 Keypad for functions 5 Button strip for dispensing unit coffee 1
3 Button strip for dispensing unit coffee 3 6 Steam lever
7 Coffee dispensing lever
6
54321
7
