Dallara Automobili – GP2 user manual 17/87
Front
MR arb - Droplink D1 (100 mm) 1.590
MR arb - Droplink D2 (55 mm) 1.627
Track 1.465 [m]
P1 P2 P3 P4 P5
Component
Stiffness
Component
Stiffness
Component
Stiffness
Component
Stiffness
Component
Stiffness
FARB
[kg/mm] [kg/mm] [kg/mm] [kg/mm] [kg/mm]
Ø 18 ø 9 @ Droplink D1
26.0 28.8 32.4 34.1 34.7
Ø 25 ø 20 @ Droplink D1
39.9 47.2 57.4 63.2 65.0
Ø 18 ø 9 @ Droplink D2
87.8 97.7 110.2 116.2 118.1
Ø 25 ø 20 @ Droplink D2
136.7 162.1 200.3 221.2 227.6
Ø 30 ø 20 @ Droplink D2
186.6 238.1 327.7 390.5 410.7
P1 P2 P3 P4 P5
Component
Stiffness
-
AntiSymmetric
Model
Component
Stiffness
-
AntiSymmetric
Model
Component
Stiffness
-
AntiSymmetric
Model
Component
Stiffness
-
AntiSymmetric
Model
Component
Stiffness
-
AntiSymmetric
Model
FARB
[kg/mm] [kg/mm] [kg/mm] [kg/mm] [kg/mm]
Ø 18 ø 9 @ Droplink D1
51.9 57.6 64.8 68.3 69.3
Ø 25 ø 20 @ Droplink D1
79.8 94.3 114.9 126.4 129.9
Ø 18 ø 9 @ Droplink D2
175.5 195.5 220.3 232.5 236.1
Ø 25 ø 20 @ Droplink D2
273.3 324.2 400.6 442.5 455.2
Ø 30 ø 20 @ Droplink D2
373.1 476.2 655.5 781.0 821.3
P1 P2 P3 P4 P5
Stiffness
@ Ground
Stiffness
@ Ground
Stiffness
@ Ground
Stiffness
@ Ground
Stiffness
@ Ground
FARB
[kg/mm] [kg/mm] [kg/mm] [kg/mm] [kg/mm]
Ø 18 ø 9 @ Droplink D1
20.5 22.8 25.6 27.0 27.4
Ø 25 ø 20 @ Droplink D1
31.6 37.3 45.4 50.0 51.4
Ø 18 ø 9 @ Droplink D2
66.3 73.9 83.2 87.8 89.2
Ø 25 ø 20 @ Droplink D2
103.2 122.5 151.3 167.1 172.0
Ø 30 ø 20 @ Droplink D2
140.9 179.9 247.6 295.0 310.3
P1 P2 P3 P4 P5
Stiffness
@ Ground
Stiffness
@ Ground
Stiffness
@ Ground
Stiffness
@ Ground
Stiffness
@ Ground
FARB
[kgm/deg] [kgm/deg] [kgm/deg] [kgm/deg] [kgm/deg]
Ø 18 ø 9 @ Droplink D1
384 427 480 506 513
Ø 25 ø 20 @ Droplink D1
591 699 851 936 962
Ø 18 ø 9 @ Droplink D2
1242 1383 1559 1645 1670
Ø 25 ø 20 @ Droplink D2
1934 2294 2834 3130 3220
Ø 30 ø 20 @ Droplink D2
2640 3369 4637 5525 5811
