Damp2Dry PACD150 - Structure Diagram

-3-
DO NOT OBSTRUCT THE AIR INLET OR OUTLET.
WARNING
1. Metal handle
2. Control panel
3. Wheels
4. Drain hose bracket
5. Air outlet grille
6. Air inlet grille
7. Power cord
8. Drain hose
STRUCTURE DIAGRAM
NOTE: You will need to install the handle.
Six bolts are included for the installation.
