6
RECOMMENDED INSTALLATION HEIGHT
From bottom edge of hand dryer above nished floor.
Men 1270 mm (50”)
Women 1194 mm (47”)
Children, 4-7 years 889 mm (35”)
Children, 8-10 years 991 mm (39”)
Children, 11-13 years 1092 mm (43”)
Children, 14-16 years 1194 mm (47”)
Wheelchair users 1016 mm (40”)
USER GUIDE
• No-touch operation.
• Shake excess water from hands.
• Place hands under the outlet to start operation.
• Rub hands lightly and rapidly.
• Stops automatically after hands are removed.
CLEANING AND MAINTENANCE
• Disconnect the electrical supply.
• Remove the two cover-mounting screws.
• Remove the cover.
• Clean the interior of the dryer and remove any dust.
• Do not soak.
• Use a damp cloth and mild cleaning solution. Never use cleaning
detergents with an abrasive effect.
• Replace the cover. Do not overtighten the screws.
