Installation Instructions
EXHAUST HOSE
INSTALLATION:
The exhaust hose and adaptor must be installed or removed in
accordance with the usage mode.
COOL, HEAT(heat pump type) or AUTO mode
FAN, DEHUMIDIFY mode
Install
Remove
1. Install the window exhaust adaptor B onto the exhaust hose as shown
in Fig.17. or Fig.18. Refer to the previous pages for window kit
installation.
2. Push the exhaust hose into the air outlet opening along the arrow
direction (See Fig.19).
îîThe hose can be compressed or extended moderately according to the
installation requirement, but it is desirable to keep the hose length to a
minimum.
IMPORTANT
DO NOT OVER BEND THE HOSE. (see Fig.21)
Fig.17
Fig.18
Fig.19
13
