INSTALLATION
INSTALLATION INSTRUCTIONS
Insert the air exhaust hose into the window sealing plate. Adjust the opening width of the window to fi t the sealing plate.
The length of the sealing plate is adjustable.
INCORRECT
INSTALLATION
It is important to keep the exhaust pipe straight. Incorrect installation will affect the effi ciency of the A/C. Do not bend the
exhaust pipe. Ensure air can fl ow freely.
WARNING
The exhaust duct is designed especially for this
model. Don’t replace it with another model’s duct
or lengthen it.
NOTICE:
The maximum length of the exhaust pipe is 59 inches
(150 cm).
6
