Operating Instructions
7
BEVERAGE STORAGE
In order to achieve the maximum storage capacity of six (6) bottles and 126 bev-
erage cans, it will be necessary to position the cans in a direct line on the upper
three glass shelves, as shown in Fig. A / Fig. B. This will allow for the storage of
forty-two (42) 355ml cans per shelf in each of the top three shelves, and six (6)
bottles on the bottom for a total storage capacity of 126 beverage cans and six (6)
wine bottles.
IMPORTANT
• The maximum* capacity of the unit is 6 (750ml) wine
bottles and 126 (355ml) beverage cans.
*When stocked as per instructions
SHELVES
To remove glass shelves:
1. Lift the back of the shelf up so the shelf pegs are above the lower rail.
2. Slide the shelf out of the unit with the pegs on the upper rail (Fig. D).
Important: Do not cover the gap on the shelves with aluminum foil or any other
material that will prevent adequate air circulation within the cabinet.
D .giF
Fig.A
Fig.B
