Operating Instructions
8
DOOR REVERSAL
Fig 1A
Fig 1B
Fig 1DFig 1C
Fig 1E
1. Bottom Hinge (Right)
2. Screws
3. Door Axis
4. Screws
5. Reed Switch
6. Top Hinge (Right)
7. Screws
8. Top Hinge (Left)
9. Decorative Nail
10. Bottom Hinge (Left)
1. Open the door to a 90° angle, take out 2 screws from the lower door axis (3), remove the door (refer to Fig. 1A), then
pull out the door and door axis (Fig. 1A).
2. Put the door safely down, unscrew 2 screws (4) at the bottom and remove the Reed switch (5), then install (5) at the
top of the door frame (Fig 1A and 1B).
3. Take out 3 screws (7) from the top hinge (right) (6) and remove the right top hinge (Fig. 1C).
4. Remove the decorative nail (9) from the top left of the cabinet and install the spare top hinge (left) (8) at the top left of
the cabinet with 3 screws (Fig. 1D).
5. According to the above procedure, install the spare lower hinge (left) (10) onto the lower left cabinet (Fig. 1E).
6. Once the door has been moved, install the door the same way that it was removed and ensure the door is properly
aligned.
7. Block the hole at the top right of the cabinet with the spare decorative nail.
Please note: Do not lay the unit on its back.
