Dancing Wings Hobby T40 - Tail Wing Assembly; Tail Assembly Steps

Assemble the Tail Wing
Cut into 4pcs small cubes
from H6 and fill in as above
photo shown.
Cut off, glue and
polish into triangle,
in order to connect
to the aileron.
Ensure the polishing
radian according to
the C14 shape.
Fix the B15 board by claw nuts when
assemble the wing.
10 11
12 13
14 15
1 2
５
T40 Trainer Assembling Manual
Here is breaking design,
please glue them together
before assembly.
