Before starting up the device, please verify the shipment for
completeness and proper condition of the items.
If there is any sign of obvious damage to the unit and/or the
power cord, do not operate the unit and contact your local dealer
from whom you received it.
Pos. Qty. d&b Code Description
[1] 1 Z2760 or Z2770 d&b 10D or 30D Amplifier, including:
[2*] 1 Z2610.xxx Power cord (specific to country*).
[3] 9 3-pin Phoenix Euroblock female:
▪ Intended for the INPUT/LINK/FAULT connector sockets.
▪ Connector type: MSTB 2,5 / 3-STZ - Order code: 1776168
[4] 2 4-pin Phoenix Euroblock male:
▪ Intended for the SPEAKER OUTPUTS connector sockets.
▪ Connector type: IPC 5/ 4-STF-7,62 - Order code: 1709173
[5] 1 6-pin Phoenix Euroblock female:
▪ Intended for the GPIO connector socket.
▪ Connector type: MSTB 2,5/ 6-STZ - Order code: 1776126
[6] 1 Z6116 RJ 45 M Terminator for the last device of a CAN-Bus segment.
[7] 1 D2026.EN .01 10D/30D Manual.
Z2610.000
3-pin Schuko
CEE 7/7
Z2610.010
3-pin GB
BS 1363A
Z2610.020
3-pin USA
NEMA 5-15P
Z2610.030
3-pin Japan
NEMA 5-15P
Z2610.040
3-pin South Korea
KS C8305
Z2610.050
3-pin Australia
AS 3112
Z2610.060
3-pin China
GB 2099
Z2610.070
3-pin Swiss
SEV1011
Z2610.090
3-pin Denmark
Afsnit 107-2-D1
Z2610.100
3-pin South Africa
SANS 164-1
Z2610.111
3-pin Argentina
IRAM 2073
Z2610.120
3-pin Brazil
NBR 14136
*Mains plug types and associated standards
(Graphics are similar illustrations only and not in scale)
1. Scope of supply
d&b 10D/30D Manual 1.10 en 5
