D&D Technologies LokkLatch Magnetic - LOKK Latch Magnetic Keeper and Alignment; Keeper Installation and Vertical Alignment; Horizontal Alignment and Component Joining; Removing and Replacing Screw Covers

Adjust keeper so that the raised bump
aligns with same on latch.
LLMINSTR000PA • instr LL MAGNETIC 3 4 13
MAINTENANCE: REMOVE KEY FROM LOCK AFTER USE. Do not lubricate
with petroleum-based products. Ensure all screws are tightened firmly
and that the latch is kept free of ice, dirt and other debris which could
impair performance. Periodic horizontal and/or vertical adjustment may
be required.
9
12
Hi-Performance Hardware
10
Tube helps protect locks from corrosion.
NOT mandatory.
Hole # 2 on fitting jig is for recessing side
fixing legs on Latch for wood gates
#
2
5
/8” (16mm)
11
WIND SCREW TO JOIN COMPONENTS
Removing Screw Covers (if necessary)
1. Insert blade horizontally underneath cover
2. Twist screwdriver and remove
3. See Step 8 to replace
Adjust keeper so that the raised bump
aligns with same on latch
A
B
#
2
FENCE POST
Poste de cerca
Poteau de cl
ô
ture
FENCE POST
Poste de cerca
Poteau de cl
ô
ture
MARK AND INSTALL KEEPER TO POST
CHECK VERTICAL ALIGNMENT
G
A
T
E
F
R
A
M
E
CHECK HORIZONTAL ALIGNMENT
