D&H DH05A - Introduction

4
DH05A/B
DH10A/B
FH05A
Specifications
Dimensions [mm]
Total load
Maximum motor current
Maximum operating voltage
Function outputs light: LV, LR
Function outputs AUX1, AUX2
SUSI interface
Connection options
Without connection wires
With ribbon cable for interface per NEM651
With connection wires
13,2 x 6,8 x 1,4
0,5 A
0,5 A
18 V
each 150 mA
each 300 mA
not available
DH05A/B-0
DH05A/B-1
DH05A/B-3
14,3 x 9,2 x 1,8
1,0 A
1,0 A
30 V
each 150 mA
each 300 mA
not available
DH10A/B-0
DH10A/B-1
DH10A/B-3
13,7 x 7,8 x 1,5
0,5 A
--
30 V
each 150 mA
each 300 mA
available
FH05A-0
FH05A-1
FH05A-3
1 Introduction
The locomotive decoder DH05A/B, DH10A/B and FH05A are compatible with the protocols of SelecTRIX
Standard SX1 / SX2 as well as with NMRA-DCC-Standard. They can be controlled by every central control
unit working with one of these data formats.
They can be used for normal direct current motors as well as for coreless motors.
The operation on alternating current supplied layouts with switching impulse is not allowed. The
impulse excitation will destroy the decoder.
