Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
71
Locomotive/Vehicle function decoder from firmware version 3.12
CV
Name and definition Range
Standard
153
Initial mapping (not relevant to PD*)
Bit Function Value Bit Function Value
0........LV ............................... 1 4 ......AUX3 ...................................... 16
1........LR ..............................2 5 ......AUX4 ...................................... 32
2........AUX1 .........................4 6 ......AUX5 ...................................... 64
3........AUX2 .........................8 7 ......AUX6 ..................................... 128
These function outputs are active as soon as the decoder is addressed
(without active function key). Thus, for example, the switchover of the sliding contacts
can be realized in connection with the conditions.
0-255 0
154
Brake ramp forward and backward (see CV27, not relevant to PD05A/PD06A)
Recommended for constant braking distance: CV48 = 0
0 = deactivated
If maximum speed step braking time is adjusted in seconds times 8, at smaller speed
steps the decoder generates the brake ramp independently
0-255 0
155
Brake ramp backward
(see CV154)
0 = value from CV154 is used
Alows different brake times forward and backward
0-255 0
156 Dimming mask for low beam light (see CV53)
Bit Function Value Bit Function Value
0........LV
............................... 1 4 ......Currently without function ...... 16
1........LR ..............................2 5 ......Currently without function ......32
2........AUX1 .........................4 6 ......Currently without function ......64
3........AUX2 .........................8 7 ......Currently without function ....128
0-15 3
157 Conditions for low beam light
(see CV145) 0-161 0
