DANE-ELEC SO SMART PVR - Front Panel; Back Panel

English
Download User Manual on www.danedigital.com
10
Front Panel
1
Direction key
(up/ down/ left/ right)
5 Power button
2 Direction key OK (press) 6 IR reception part
3
Direction key OK (press by 3 seconds
or longer -> move to HOME)
7 iPod expand connections
4 LCD status window
Back Panel
1 Optical terminal 8 Input composite terminal
2 10/100Mbps LAN port 9 Input stereo RCA terminal
3 USB2.0 A-type 2-port host 10 Fan
4 Output Stereo RCA terminal 11 USB 2.0 A-type slave
5 Output Component terminal 12 Power
6 Output Composite terminal 13 Coaxial terminal
7 HDMl terminal
7
6 5 4 1 2 3
1 7 5 4 9
8
10
31112
2 13
6
