PN
U
Parameter Factory setting Range
Change
s
4-Set-
up
Conver-
sion
Data
# description during operation index type
400 Brake function/overvoltage control Off Yes No. 0 5
401 Brake resistor, ohm Depends on the unit Yes No. -1 6
402 Braking energy limit, kW Depends on the unit Yes No. 2 6
403 Power monitoring On Yes No. 0 5
404 Brake check Off Yes No. 0 5
405 Reset function Manual reset Yes Yes 0 5
406 Automatic restart time 5 sec 0-10 sec Yes Yes 0 5
407 Line Failure No function Yes Yes 0 5
408 Quick discharge Not possible Yes Yes 0 5
409 Trip delay torque Off 0-60 sec Yes Yes 0 5
410 Trip delay inverter Depends on type of unit 0-35 sec Yes Yes 0 5
411 Switching frequency Depends on type of unit 1.5-14 kHz Yes Yes 2 6
412 Output frequency dependent switching
frequency
Not possible Yes Yes 0 5
413 Overmodulation function On Yes Yes -1 5
414 Minimum feedback 0.000 -100,000.000
- FB
HIGH
Yes Yes -3 4
415 Maximum feedback 1500.000 FB
LOW
-
100,000.000
Yes Yes -3 4
416 Process unit % Yes Yes 0 5
417 Speed PID proportional gain 0.015 0.000 - 0.150 Yes Yes -3 6
418 Speed PID integration time 8 ms 2.00 - 999.99
ms
Yes Yes -4 7
419 Speed PID differentiation time 30 ms 0.00 - 200.00
ms
Yes Yes -4 6
420 Speed PID diff. gain ratio 5.0 5.0 - 50.0 Yes Yes -1 6
421 Speed PID low-pass filter 10 ms 5 - 200 ms Yes Yes -4 6
422 U 0 voltage at 0 Hz 20.0 V 0.0 - parame-
ter 103
Yes Yes -1 6
423 U 1 voltage parameter 103 0.0 - U
VLT, MAX
Yes Yes -1 6
424 F 1 frequency parameter 104 0.0 - parame-
ter 426
Yes Yes -1 6
425 U 2 voltage parameter 103 0.0 - U
VLT, MAX
Yes Yes -1 6
426 F 2 frequency parameter 104 par. 424 - par.
428
Yes Yes -1 6
427 U 3 voltage parameter 103 0.0 - U
VLT, MAX
Yes Yes -1 6
428 F 3 frequency parameter 104 par. 426 - par.
430
Yes Yes -1 6
429 U 4 voltage parameter 103 0.0 - U
VLT, MAX
Yes Yes -1 6
VLT
®
5000 Series
224 MG.51.C5.22 - VLT
p
is a registered Danfoss trademark.
