VLT
®
5000/5000 Flux/6000 HVAC/8000 AQUA PROFIBUS
MG.90.D1.02 – VLT is a registered Danfoss trademark
61
Parameter list
5
6
6
5
5
5
5
5
5
5
5
6
5
5
4
4
5
6
7
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
7
5
5
6
6
7
6
6
6
5
5
3
4
6
6
4
5
0
-1
2
0
0
0
0
0
0
0
0
2
0
-1
-3
-3
0
-3
-4
-4
-1
-4
-1
-1
-1
-1
-1
-1
-1
-1
-1
-1
-1
0
-3
0
0
-1
-2
-2
-2
-1
-2
0
0
0
-2
-2
0
0
0
PNU Parameter Factory setting Range Changes Conversion
# description during Index
operation
400 Brake function/overvoltage control Off Yes No
401 Brake resistor, ohm Depends on the unit Yes No
402 Brake power limit, kW Depends on the unit Yes No
403 Power monitoring On Yes No
404 Brake check Off Yes No
405 Reset function Manual reset Yes Yes
406 Automatic restart time 5 sec. 0 - 10 sec. Yes Yes
407 Mains Failure No function Yes Yes
408 Quick discharge Not possible Yes Yes
409 Trip delay torque Off 0 - 60 sec. Yes Yes
410 Trip delay-inverter Depends on type of unit 0 - 35 sec. Yes Yes
411 Switching frequency Depends on type of unit 3 - 14 kHz Yes Yes
412 Output frequency dependent Not possible Yes Yes
switching frequency
413 Overmodulation function On Yes Yes
414 Minimum feedback 0.000 FB
HIGH
- 100,000.000 Yes Yes
415 Maximum feedback 1500.000 FB
LOW
- 100,000.000 Yes Yes
416 Process unit % Yes Yes
417 Speed PID proportional gain 0.015 0.000 - 0.150 Yes Yes
418 Speed PID integration time 8 ms 2.00 - 999.99 ms Yes Yes
419 Speed PID differentiation time 30 ms 0.00 - 200.00 ms Yes Yes
420 Speed PID diff. gain ratio 5.0 5.0 - 50.0 Yes Yes
421 Speed PID low-pass filter 10 ms 5 - 200 ms Yes Yes
422 U 0 voltage at 0 Hz 20.0 V 0.0 - parameter 103 Yes Yes
423 U 1 voltage parameter 103 0.0 - U
VLT, MAX
Ye s Ye s
424 F 1 frequency parameter 104 0.0 - parameter 426 Yes Yes
425 U 2 voltage parameter 103 0.0 - U
VLT, MAX
Ye s Ye s
426 F 2 frequency parameter 104 par.424-par.428 Yes Yes
427 U 3 voltage parameter 103 0.0 - U
VLT, MAX
Ye s Ye s
428 F 3 frequency parameter 104 par.426 -par.430 Yes Yes
429 U 4 voltage parameter 103 0.0 - U
VLT, MAX
Ye s Ye s
430 F 4 frequency parameter 104 par.426-par.432 Yes Yes
431 U 5 voltage parameter 103 0.0 - U
VLT, MAX
Ye s Ye s
432 F 5 frequency parameter 104 par.426 - 1000 Hz Yes Yes
433 Torque proportional gain 100% 0 (OFF) - 500% Yes Yes
434 Torque integral time 0.02 sec. 0.002 - 2.000 sec. Yes Yes
437 Process PID Normal/inverse control Normal Yes Yes
438 Process PID anti windup On Yes Yes
439 Process PID start frequency parameter 201 f
MIN
- f
MAX
Ye s Ye s
440 Process PID proportional gain 0.01 0.00 - 10.00 Yes Yes
441 Process PID integral time 9999.99 sec. (OFF) 0.01 - 9999.99 sec. Yes Yes
442 Process PID differentiation time 0.00 sec. (OFF) 0.00 - 10.00 sec. Yes Yes
443 Process PID diff. gain limit 5.0 5.0 - 50.0 Yes Yes
444 Process PID lowpass filter time 0.01 0.01 - 10.00 Yes Yes
445 Flying start Disable Yes Yes
446 Switching pattern SFAVM Yes Yes
447 Torque compensation 100% -100 - +100% Yes Yes
448 Gear ratio 1 0.001 - 100.000 No Yes
449 Friction loss 0% 0 - 50% No Yes
450 Mains voltage at mains fault Depends on unit Depends on unit Yes Yes
453 Speed closed loop gear ratio 1 0.01-100 No Yes
454 Dead time compensation ON No No
4-Setup
Data
type
■ Parameter list VLT 5000
