PNU Parameter Factory setting Range Changes 4-Set-up
Conver-
sion
Data
# description during operation index type
500 Address 1 0 - 126 Yes No. 0 6
501 Baud rate 9600 baud Yes No. 0 5
502 Coasting Logic or Yes Yes 0 5
503 Quick stop Logic or Yes Yes 0 5
504 DC-brake Logic or Yes Yes 0 5
505 Start Logic or Yes Yes 0 5
506 Reversing Logic or Yes Yes 0 5
507 Selection of set-up Logic or Yes Yes 0 5
508 Selection of speed Logic or Yes Yes 0 5
509 Bus jog 1 10.0 Hz 0.0 - parameter 202 Yes Yes -1 6
510 Bus jog 2 10.0 Hz 0.0 - parameter 202 Yes Yes -1 6
511
512 Telegram profile FC Drive No. Yes 0 5
513 Bus time interval 1 sec 1 - 99 s Yes Yes 0 5
514 Bus time interval function Off Yes Yes 0 5
515 Data readout: Reference % No. No. -1 3
516 Data readout: Reference unit No. No. -3 4
517 Data readout: Feedback No. No. -3 4
518 Data readout: Frequency No. No. -1 6
519 Data readout: Frequency x Scaling No. No. -2 7
520 Data readout: Current No. No. -2 7
521 Data readout: Torque No. No. -1 3
522 Data readout: Power, kW No. No. 1 7
523 Data readout: Power, HP No. No. -2 7
524 Data readout: Motor voltage No. No. -1 6
525 Data readout: DC link voltage No. No. 0 6
526 Data readout: Motor temp. No. No. 0 5
527 Data readout: VLT temp. No. No. 0 5
528 Data readout: Digital input No. No. 0 5
529 Data readout: Terminal 53,
analog input
No. No. -2 3
530 Data readout: Terminal 54,
analog input
No. No. -2 3
531 Data readout: Terminal 60,
analog input
No. No. -5 3
532 Data readout: Pulse reference No. No. -1 7
533 Data readout: External reference % No. No. -1 3
534 Data readout: Status word, binary No. No. 0 6
535 Data readout: Braking energy/2 min. No. No. 2 6
536 Data readout: braking energy/sec No. No. 2 6
537 Data readout: Heatsink temperature No. No. 0 5
538 Data readout: Alarm word, binary No. No. 0 7
539 Data readout: VLT Control word, binary No. No. 0 6
540 Data readout: Warning word, 1 No. No. 0 7
541 Data readout: Extended Status word No. No. 0 7
553 Display text 1 No. No. 0 9
554 Display text 2 No. No. 0 9
557 Data readout: Motor RPM No. No. 0 4
558 Data readout: Motor RPM x scaling No. No. -2 4
580 Defined parameter No. No. 0 6
581 Defined parameter No. No. 0 6
582 Defined parameter No. No. 0 6
VLT
®
5000 Series
226 MG.51.C5.22 - VLT
p
is a registered Danfoss trademark.
