Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
20-0* Feedback 20-00 Feedback 1 Source [2] Analog input 54 All set-ups TRUE - Uint8 20-01 Feedback 1 Conversion [2] Pressure to temperature All set-ups FALSE - Uint8
20-02 Feedback 1 Source Unit null All set-ups TRUE - Uint8
20-03 Feedback 2 Source [0] No function All set-ups TRUE - Uint8
20-04 Feedback 2 Conversion [0] Linear All set-ups FALSE - Uint8
20-05 Feedback 2 Source Unit null All set-ups TRUE - Uint8
20-06 Feedback 3 Source [0] No function All set-ups TRUE - Uint8
20-07 Feedback 3 Conversion [0] Linear All set-ups FALSE - Uint8
20-08 Feedback 3 Source Unit null All set-ups TRUE - Uint8
20-12 Reference/Feedback Unit null All set-ups TRUE - Uint8 20-2* Feedback/Setpoint 20-20 Feedback Function [3] Minimum All set-ups TRUE - Uint8 20-21 Setpoint 1 0 ProcessCtrlUnit All set-ups TRUE -3 Int32 20-22 Setpoint 2 0.000 ProcessCtrlUnit All set-ups TRUE -3 Int32
20-23 Setpoint 3 0.000 ProcessCtrlUnit All set-ups TRUE -3 Int32
20-25 Setpoint Type null All set-ups TRUE - Uint8 20-3* Feedback Adv. Conv 20-30 Refrigerant [19] R404A All set-ups TRUE - Uint8 20-31 User Defined Refrigerant A1 10.0000 N/A All set-ups TRUE -4 Uint32 20-32 User Defined Refrigerant A2 -2250.00 N/A All set-ups TRUE -2 Int32
20-33
User Defined Refrigerant A3 250.000 N/A All set-ups TRUE -3 Uint32
20-4* Thermostat/Pressostat 20-40 Thermostat/Pressostat Function null All set-ups FALSE - Uint8 20-41 Cut-out Value ExpressionLimit All set-ups TRUE -3 Int32
20-42 Cut-in Value ExpressionLimit All set-ups TRUE -3 Int32
20-7* PID Autotuning 20-70 Closed Loop Type [0] Auto 2 set-ups TRUE - Uint8 20-71 PID Performance [0] Normal 2 set-ups TRUE - Uint8
20-72 PID Output Change 0.10 N/A 2 set-ups TRUE -2 Uint16
20-73 Minimum Feedback Level -999999.000 ProcessCtrlUnit 2 set-ups TRUE -3 Int32
20-74 Maximum Feedback Level 999999.000 ProcessCtrlUnit 2 set-ups TRUE -3 Int32
20-79 PID Autotuning [0] Disabled All set-ups TRUE - Uint8 20-8* PID Basic Settings 20-81 PID Normal/ Inverse Control [1] Inverse All set-ups TRUE - Uint8 20-82 PID Start Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16 20-83 PID Start Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
20-84
On Reference Bandwidth 5 % All set-ups TRUE 0 Uint8
20-9* PID Controller 20-91 PID Anti Windup [1] On All set-ups TRUE - Uint8 20-93 PID Proportional Gain 0.50 N/A All set-ups TRUE -2 Uint16
20-94 PID Integral Time 30.00 s All set-ups TRUE -2 Uint32
20-95 PID Differentiation Time 0.00 s All set-ups TRUE -2 Uint16
20-96 PID Diff. Gain Limit 5.0 N/A All set-ups TRUE -1 Uint16
6.2.15 20-** FC Closed Loop
