Danfoss ADAP-KOOL AKD 102 User Manual

380 - 480 V
380 - 500 V
Fuses Disconnect Fuses RFI RFI Fuses RFI Disconnect
Fuses
D1 All D1 power sizes 176F8442 176F8450 176F8444 176F8448 176F8446
D2 All D2 power sizes 176F8443 176F8441 176F8445 176F8449 176F8447
525 - 690 V Fuses Disconnect Fuses RFI RFI Fuses RFI Disconnect
Fuses
D1 AKD 102/ : 45-90 kW
: 37-75 kW
175L8829 175L8828 175L8777 NA NA
AKD 102/ : 110-160 kW
: 90-132 kW
175L8442 175L8445 175L8777 NA NA
D2 All D2power sizes 175L8827 175L8826 175L8825 NA NA
NB!
For further information, please see the Instruction Sheet,
175R5795
3.4.5 Installation of Mains Shield for Frequency Converters
This section is for the installation of a mains shield for the frequency converter series with D1, D2 and E1 frames. It is not possible to install in the IP00/
Chassis versions as these have included as standard a metal cover. These shields satisfy VBG-4 requirements.
Ordering numbers:
Frames D1 and D2 : 176F0799
NB!
For further information, please see the Instruction Sheet,
175R5923
ADAP-KOOL
®
Drive AKD 102 High Power 3 Mechanical Installation
MG.11.O1.02 - ADAP-KOOL
®
is a registered Danfoss trademark 31
3
