Table 1. Outdoor / Defrost sensor
°C 150 ohm, Ω
-30 1884
-25 1443
-20 1115
-15 868
-10 681
-5 538
0 428
5 343
10 276
15 224
20 183
25 150
30 124
35 103
40 86
Table 2. PT1000 sensor
°C 1000 ohm, Ω
0 1000
10 1039
20 1078
30 1117
40 1155
50 1194
60 1232
70 1271
Table 3. Other sensors
°C 22 kilo ohm, kΩ
0 66,3
5 52,4
10 41,8
15 33,5
20 27,1
25 22,0
30 18,0
35 14,8
40 12,2
45 10,1
50 8,5
55 7,1
60 6,0
65 5,0
70 4,2
75 3,7
80 3,1
85 2,7
3.3.1 Measurement checking sensors during fault tracing
1.
Disconnect the relevant sensor from I/O-card/terminal block.
2. Measure the resistance for the sensor and any extension cables.
3. Then measure the sensor only.
Note! To ensure the sensor value the actual temperature must be checked against the measured
resistance.
12 – Service instructions VMGFJ102
