Danfoss DHP-AQ Installation Instructions

The heat pump control and control unit are fused with fuses F1 and F2 (see figures below).
4
1
2
3
2
3
2
A
B C D
Symbol explanation
A Heat pump
B Control unit DHP-AQ Mini
C Control unit DHP-AQ Midi
D Control unit DHP-AQ Maxi
1 Fuse F1
2 Fuse F2
3 Overheating protection
4 Overcurrent protection
Installation instructions VMGFD102 – 23
