Warning symbols
Warning, danger!
Read the documentation provided.
Read the documentation provided.
Warning, hazardous electrical voltage!
Warning, hot surfaces!
Warning, moving parts!
Warning, risk of crushing injury!
Electrical components
Component, normal Component, accessory
3 Outdoor unit 362 Shunt valve
50 Outdoor sensor 363 Exchange valve hot water
54 Hot water sensor 365 Supply line sensor
55 Sensor hot-water top 366 Return line sensor
71 Flow sensor 406 Room sensor
304 Circulation pump 408 EVU
353 Drip tray 417 Defrost sensor
Example:
Room sensor
4 – Installation instructions VMGFD102
