Menu selection Meaning Factory setting
FACTORY SET CANCEL = starting point, no changes made.
RADIATOR = reset factory settings for radiator system
FLOOR = reset factory settings for under floor heating
-
RESET OPER.
TIME
0 = no reset of operating times
1 = reset of operating times to zero
-
SENSOR CALI-
BRATION
Following sensors can be found in the installation:
OUTDOOR
SUPPLY LINE
RETURN LINE
HOT WATER
BRINE IN
BRINE OUT
DEFR SENSOR
POOL
SHUNT GROUP
HGW TEMPERATURE
BUFFER TANK
2ND HEAT CIR.
SYSTEM SUPPLY
EXTERNAL FACTOR Affects sensors that are installed inside the
heat pump.
0, (range: -5°C / 5°C)
0, (range: -5°C / 5°C)
0, (range: -5°C / 5°C)
0, (range: -5°C / 5°C)
0, (range: -5°C / 5°C)
0, (range: -5°C / 5°C)
0, (range: -5°C / 5°C)
0, (range: -5°C / 5°C)
0, (range: -5°C / 5°C)
0, (range: -5°C / 5°C)
0, (range: -5°C / 5°C)
0, (range: -5°C / 5°C)
0, (range: -5°C / 5°C)
0 (5°C for DHP-A, DHP-A Opti, DHP-AL,
DHP-AL Opti)
(range: 0°C / 20°C)
VERSION Shows the software version which is stored on the display card
respectively the I/O-card.
DISPLAY: V X.X
I/O-CARD: V X.X
-
LOG TIME Time interval between collection points of temperature history
in minutes. The history graphs always show the 60 last collec-
tion points, which means that the graphs can display history
from 1 hour up to 60 hours ago.
(The function is not active if there is an active alarm).
1M
(range: 1M / 60M)
BRINE TIME ON The brine pump starts the set number of seconds before the
compressor. Applies at start of heat pump.
30S
(range: 10S / 90S)
BRINE TIME OFF The brine pump stops the set number of seconds after the com-
pressor. Applies at stop of heat pump.
30S
(range: 10S / 60S)
Installation instructions VMBMA1002 – 59
