Menu selection Meaning Factory
setting
BRINE OUT Shows the actual temperature for brine out. -
POOL Only appears if POOL is selected. Shows the actual pool temperature. The set pool temperature is
shown in brackets.
-
COOLING Indicates temperature.
SHUNT GROUP Only appears if SHUNT GROUP is selected. Shows the actual supply temperature. The calculated supply
temperature to the shunt group is within brackets.
-
2ND HEAT CIR. Shows the temperature of the second heating circuit if installed by the buffer tank system.
CURRENT Only appears if CURRENT LIMITER is selected. Shows the actual current consumption. The set value for
MAX CURRENT is shown in brackets.
-
8.5 Sub-menu OPERAT.TIME
Menu selection Meaning Factory setting
HEAT PUMP Compressor operating time for both heating and hot water production. -
AUX. HEAT 1 OPERAT. TIME AUX. HEATER 1. -
AUX. HEAT 2 OPERAT. TIME AUX. HEATER 2.
AUX. HEAT 3 OPERAT. TIME AUX. HEATER 3.
HOT WATER Operating time for hot water with compressor. -
COOLING Operating time cooling.
ACT COOLING Operating time active cooling.
8.6 Sub-menu DEFROST
Menu selection Meaning Factory setting
DEFROSTS Total number of defrosts carried out. -
BETW. 2 DEFR The operating time of the compressor in minutes between the two last defrosts. -
TIME LAST DEFR The operating time of the compressor in minutes since last defrost. -
FAN H OFF AT High speed is deactivated at this temperature and low speed is activated. 12°C(range: 10°C / 20°C)
DEFROST CURVE Used to change the angle of the defrost curve using + or– (Change the start temperature
for defrost).
-10°C(range: -13°C / -7°C)
MANUAL DEFR Used to perform a manual defrost. Started using + or -. 0(range: 0 / 1)
8.7 Sub-menu LANGUAGE
Menu selection
SVENSKA
ENGLISH
DEUTSCH
NEDERLANDS
FRANÇAIS
ESPAÑOL
ITALIANO
NORSK
DANSK
SUOMI
EESTI
Installation Guide Domestic heat pumps
Danfoss Heating Solutions VMGFQ102
41
