FCM 300 / FCD 300 / VLT
®
2800 / DP V1 PROFIBUS
904 PPO type select for DP
(PPO TYPE SELECT)
Value:
✭PPO type 1 (PPO TYPE 1)
[900]
PPO type 2 (PPO TYPE 2)
[901]
PPO type 3 (PPO TYPE 3)
[902]
PPO type 4 (PPO TYPE 4)
[903]
PPO type 5 (PPO TYPE 5)
[905]
PPO type 6 (PPO TYPE 6)
[906]
PPO type 7 (PPO TYPE 7)
[907]
PPO type 8 (PPO TYPE 8)
[908]
Function:
Read out of PPO type set b y the master.
Description of choice:
- PPO type 1: 12 byte PPO w ith parameter
channel for read and write of parame ters and 4
bytes of process data (control/status word and
reference/actual output frequency).
- PPO type 2: 20 byte PPO as PPO type 1 with 8
additional bytes of selectable process data.
- PPO type 3: 4 byte process data (control/status
word and reference/actual output frequency).
- PPO type 4: 12 byte process d ata, as process
data part of PPO type 2.
- PPO type 5: 28 byte as PPO type 2 with 8
additional bytes of selectable process data.
- PPO type 6: control/status word and
reference/actual output frequency and additional
4 byte process data.
- PPO type 7: control/status word and
reference/actual output frequency and additional
12 byte process data.
- PPO type 8: control/status word and
reference/actual output frequency and additional
16 byte process data.
A d etaile d description of the PPO types can be
found in section PPO descript ion.
915 PCD config. write
(PCD IN WR-)
Value:
Sub index 1 (PCD 3)
[Parameter #]
Sub index 2
[Parameter #]
Sub index 3
[Parameter #]
Sub index 4
[Parameter #]
Sub index 5
[Parameter #]
Sub index 6
[Parameter #]
Sub index 7
[Parameter #]
Sub index 8
[Parameter #]
Function:
Different parameters m ay be assigned to the PCD 3-10
of the PPOs (the max.number of the PCD depends on
the PPO type). The values in PCD 3-10 are written to
the selected parameters in form of data values.
Write ac cess to parameter 915 via Profibus or
standard RS 485 or LCP2.
Description of choice:
The sequence of the sub-indexes corresponds to the
sequence of the P C D in the PPO, i.e. s ub-inde x 1 =
PCD 3 , sub-index 2 = PCD 4 etc. Each sub-index
may contain the number of any frequency con verter
parameter that can be written to. Each PCD is defined
as a w ord. If data should be written to a parameter
that has an attribute of Integer 32 or Unsigned 32
the parameter number should be defined twice in
the following PCD’s: PCD 3 and 4, PCD 5 and 6,
PCD 7 and 8 or PCD 9 and 10. See example by
parameter 916 PCD config. Read.
NB!:
First the odd subindex must be w ritten.
Otherwise the data will be interpreted
as 2 low words.
916 PCD config. read
(PCD IN RD-)
Value:
Sub index 1 (PCD 3)
[Parameter #]
Sub index 2
[Parameter #]
Sub index 3
[Parameter #]
Sub index 4
[Parameter #]
Sub index 5
[Parameter #]
Sub index 6
[Parameter #]
Sub index 7
[Parameter #]
Sub index 8
[Parameter #]
Function:
Different parameters m ay be assigned to the PCD 3-10
of the PPOs (the max.number of the PCD depends on
the PPO type). The values in PCD 3-10 are read from
the selected parameters in form of data values.
Write ac cess to parameter 916 via Profibus or
standard RS 485 or LCP2.
Description of choice:
The sequence of the sub-indexes corresponds to the
sequence of the P C D in the PPO, i.e. s ub-inde x 1 =
PCD 3 , sub-index 2 = PCD 4 etc. Each sub-index
may contain the number of any VLT parameter.
MG.90.A5.02 - VLT is a registered Danfoss t rademark
34
