Danfoss FCM 300 User Manual

FCM 300 / FCD 300 / VLT
®
2800 / DP V1 PROFIBUS
Parameters
967 Control word
Value:
16 bits binary code
Function:
This parameter is read only and only accessible
via the Profibus communic ation.
968 Status word
Value:
Read only
Function:
This parameter is read only and only accessible
via the Profibus communic ation.
970 Edit set up selection
(EDIT SETUP SELECT)
Value:
Factory setup (FACTORY SETUP)
[0]
Setup 1 (SETUP 1)
[1]
Setup 2 (SETUP 2)
[2]
Setup 3 (SETUP 3)
[3]
Setup 4 (SETUP 4)
[4]
✭Active setup (ACTIVE SETUP)
[5]
Function:
NB!:
FCM Setyp only 1 and 2!
This parameter is to be used for access ing drives
parameters in various setups from a master class
1 (eg. P LC), please refer to the section Read /Write
on frequency converter parameters.
971 Store data values
(STORE DATA VALUE)
Value:
✭No action (NO ACTION)
[0]
Store active setup (STORE ACTIVE SETUP)
[1]
Store edit setup (STORE EDIT SETUP)
[2]
Store all setups (STORE ALL SETUPS)
[3]
Function:
Parameter values changed via profibus is only stored
in ram meaning that the changes are lost at powe r
down. This parameter is used to activate a function
that stores all p arameter values in the EEPROM thus
retaining changed parameter values at p ow er down.
Description of choice:
No action: The store function is inactive.
Storeactivesetup:All parameter values in the active
setup will be stored in the EEPROM. The value returns to
No action when all parameter values have been stored.
Store edit setup (p. 970): All parameter values
in the setup you are editing will be stored in the
EEPROM. The value returns to No action when all
parameter values have been stored.
Store all setups: All parameter values in both setups
will be stored in the EEPR O M . The value returns to No
action when all parameter values have been stored.
980-982 Defined parameters
(DEFINED PNU’S)
Value:
Read only
Function:
The three parameters hold a list of all the parameters
that are defined in the FCM 300/FCD 300/VLT 2800.
It is possible to read si ngle elements of the list by DP
by using the c orresponding s ubindex. The subindexes
start at 1 and follow the order of the parameter numbers.
Each parameter holds up to 116 elements
(parameter numbers).
When a 0 is returned as parameter number the list ends.
990-992 Modified parameters
(MODIFIED PNU’S)
Value:
Read only
Function:
The three param eters hold a list of all the FCM
300/FCD 300/VLT 2800 parameters that have been
changed from factory setting. It is possible to
read single elements of the list by DP by using the
corresponding subindex. The subindexes start at
1 and follow the order of the parameter numbers.
Each parameter holds up to 116 elements (parameter
numbers). The number of parameters (990, 991
and 992) in use depends on how m any parameters
have been cha n ged from factory setting.
MG.90.A5.02 - VLT i s a registered Danfoss trademark
37
