M1 M2 M3 M4
ICF 50-4
33 Nm
(24.3 ft lbs)
33 Nm
(24.3 ft lbs)
140 Nm
(103.3 ft lbs)
33 Nm
(24.3 ft lbs)
ICF 65-3
57 Nm
(42 ft lbs)
150 Nm
(110.6 ft lbs)
57 Nm
(42 ft lbs)
ICF 50-4 110 Nm (81.1 ft lbs)
ICF 65-3 110 Nm (81.1 ft lbs)
8a
8b
5
6
7
2
3
3
1
2
2
2
1
1
2
3
3
ICS / ICSH
ICM
ICLX
ICF 50-4 60 Nm (44.3 ft lbs)
ICF 65-3 60 Nm (44.3 ft lbs)
ICF 50-4 45 Nm (33.2 ft lbs)
Maintenance  Instandhaltung  Maintenance  Mantenimiento 
Manutenção  Serwis  Техническое обслуживание  维护
