VISUO14F Danfoss Heating Solutions4
RET2001M & TP5001M
1. Installation Steps
User Guide can be downloaded from: heating.danfoss.com.
1. Installation must be done by an authorised
electrician.
2. The room thermostat should be installed at approx.
1.5 m above floor and where the effects of sunlight,
draught or other heat sources (eg. TV’s) are avoided,
see fig. 1 on page 44.
3. First loosen lower retaining screw and carefully
remove back plate, see fig. 2.
4. Mount back plate direct to wall or on wall box and
wire according to application, see figs 3 & 5 accord-
ing to application.
5. Locate hooks at top of front part into top of back
plate and lower into position and tighten retaining
screw.
2. Dimensions and Wiring
See fig. 4 for dimensions and fig. 5 for wiring diagram
on page 45.
Installation Guide
EN
