OperatingguideTermixATBTD
Sideplates
Fastentherightandleftsideplatesbyplacingthekeyholesover
thescrewsonthesidesofthewallbracket.
1Bottompanel
Slidetheslotsinthebottompanelontothe2bushesintheside
plates,andfastenthepanelwiththe2screwsinthefront.
2Topplate
Mountthetopplate.
3Frontcover
Mountthefrontcoverbyloweringthekeyholesontothescrews
inthesideplates.
4Clockpanel
Mounttheclockpanelbyloweringthekeyholesontothescrews
inthesideplates.
DanfossDistrictEnergy
VI.JV.Y3.02/LUK40692
DEN-GT
7
