OperatingguideTermixATBTD
6.2SchematicdiagramTermixATBTD5Pipes
DHW
DCW
CWM
DH
Supply
DH
Return
Yoursubstationmightlookdifferentthantheschematicdiagramshown.
Schematicdescription
E
Hotwatertankwithcoil
4
Safetyvalve
1
Ballvalve
20
Filling/drainvalve
1A
Ballvalve,DVGW
41A
Fittingpiece,coldwatermains
2
Singlecheckvalve
59
Differentialpressure/temperatureregulatorwithowlimiting
DHW:DomesticHotWater
DCW:
DomesticColdWater
CWM:
Coldwatermains
DHSupply:DistrictHeatingSupply
DHReturn:DistrictHeatingReturn
DanfossDistrictEnergy
VI.JV.Y3.02/LUK40692
DEN-GT
9
