InstallationGuideTermixOne-B
5.2Schematicdiagram
DH
Supply
DHW
DH
Return
DCW
DH
Supply
DHW
HWC
DH
ReturnDCW
Yoursubstationmightlookdifferentthantheschematicdiagramshown.
Firstdiagram:TermixOne-Q-withGTU.
Seconddiagram:TermixOne-Q-withsafetyvalve.
Schematicdescription
B
Heatexchanger,DHW
7
Thermostaticvalve
2
Singlecheckvalve
21
Tobeorderedseparately
4
Safetyvalve
62
GTUPressureequalizer
6
Thermostatic/non-returnvalve
DHW:DomesticHotWater
DCW:
DomesticColdWater
HWC:
HotWaterCirculation
DHSupply:DistrictHeatingSupply
DHReturn:DistrictHeatingReturn
DanfossHeating
VI.CW.J3.02/LUK38000
DEN-GT
7
