Menu Structure B- Continued
Display Functions Description
Maximum values | Press OK to view Press OK to access submenu for recorded values.
↳
Submenu
AC out: 1844 W | 8.356 A 263 V
Maximum values recorded at AC output since last resetting of max. value
memory.
DC1 in: 2220 W** | 8.004 A 509 V
Maximum values recorded at DC1 input since last resetting of max. value
memory.
DC2 in: 2220 W** | 8.004 A 509 V
Maximum values recorded at DC2* input since last resetting of max. value
memory.
DC3 in: 2220 W** | 8.004 A 509 V
Maximum values recorded at DC3* input since last resetting of max. value
memory.
Total drt. Temp. - Press OK to view
Total Derating Temperature. Shows the total amount of time the inverter
has derated due to high temperature.
↳
Submenu
DC1 derate temp. | 3h 35m
DC1 Derating Temperature. Shows the amount of time the inverter has
derated due to high temperature.
DC2 derate temp. | 3h 35m
DC2* Derating Temperature. Shows the amount of time the inverter has
derated due to high temperature.
DC3 derate temp. | 3h 35m
DC3* Derating Temperature. Shows the amount of time the inverter has
derated due to high temperature.
Total drt. Grid | 0h 00 min
Total Derating Grid. Shows the amount of time the inverter has derated
due to unstable grid conditions.
Power-down time | 00600 seconds
Time before inverter goes into ‘OFF’ mode when no solar power is avail-
able.
Code numbers | PRESS OK to view Press OK to access submenu for recorded values.
↳
Submenu
Inverter code no. | Indicates inverter product code.
AC code number | C0070105602 Indicates AC module product code.
DC1 code number | C0070105402 Indicates DC1 module product code.
DC2 code number | C0070105402 Indicates DC2* module product code.
DC3 code number | C0070105402 Indicates DC3* module product code.
Serial numbers | Press OK to view Press OK to go to submenu for recorded values.
↳
Submenu
Inverter SN: | Indicates inverter serial number.
AC SN: | 117500C0408 Indicates AC module serial number.
DC1 SN: | 642800C0808 Indicates DC1 module serial number.
DC2 SN: | 642800C0808 Indicates DC2* module serial number.
DC3 SN: | 642800C0808 Indicates DC3* module serial number.
Table 2.4: Overview Menu Structure B
*) The DC2 and DC3 menus are only displayed in inverters equipped with two or three inputs.
**) The maximum values for PV power may reach more than 2000 W in inverters where the inputs are connected in parallel.
This is normal.
In menu section A the display will continue to show the menu point last chosen by the user.
In menu B the display automatically switches to menu A when there has been no keyboard activity
for 3 minutes.
2. Function Description
8 L00410362-05_2q
